Verkline Front Adjustable Tubular Wishbones VAG MK7 (MQB) - Std Subframe

Verkline Front Adjustable Tubular Wishbones VAG MK7 (MQB) - Std Subframe

Verkline Front Adjustable Tubular Wishbones for VAG MK7 (MQB) Platform (Standard Subframe)

When using the car on the track the cornering forces are bending the rubber in the wishbones (control arms). Thus changing the desired geometry of the car that was set on alignment rack. This can lead to slower track times and bad tire usage.

These uniball control arms stop this from happening.

Most of the cars that are used on track are lowered compared to stock. Lowering the car has the undesirable effect of moving the chassis lower than the balljoint and excessive lowering results in the situation where the wishbone is pointing upwards at the wheel end. This means you need more steering lock when cornering, the car is sluggish to respond and doesn’t feel as communicative.

Please Note:- These can only be used with Stock VAG Front subframes

Product functionalities:

• Adjustment both caster and camber (up to -4.5 degrees in camber)
• No rubber to bend, you will not loose the geometry set when doing aliment
• Works with OEM subframe and our tubular subframes
• Enables removal of the wishbones with our the need for removal of the subframe

Features:

• T45 (BS4T45 to BS4T100) tubing
• Proven motorsport M18 uniballs (Motorsport HEAVY DUTY series from RODOBAL [Italy] with reinforced PTFE anti-friction liner, preloaded tight fit, have forged body, out of 42CrMo4 heat treated steel, for maximum load capacity. The inner ring is out of 100Cr6 carbon steel, hardened, ground and chrome plated.)
• Plug and play to use with the car inc xenon sensors
• Possibility to add Audi 8V air ducts to the wishbones (air ducts are not included)

Properties:

• Tensile: 700 – 900MPa,
• 0.2% Yield 620MPa minimum
• Hardness Test: 201min – 262 max HB or 210min – 275max HV.

This Kit Consists of the Following:

2x (pair for one car) front wishbones with all hardware for install
4x rubber dust caps for uniball protection

If you have the Verkline Tubular Subframe, you will require this kit:

https://drvnbydarkside.co.uk/products/verkline-front-adjustable-tubular-wishbones-for-mqb-platform.html

This Kit will fit the following Vehicles:

Audi A3 / S3 / RS3 (8V and 8VFL MQB) - 2013 Onwards
Audi TT / TTS / TTRS (8S) - 2014
Volkswagen Golf / GTI / R (Mk7 MQB) - 2012
Seat Leon (5F MQB) - 2012
Other MQB Based Cars

Sold for off road, track and racing applications only. Installation of this rear arm kit might introduce some additional some NVH (noise, vibration, and harshness) transfer into the cabin.

Brake disc clearance is reduced by about 2[mm] in relation to OEM wishbones - keep this in mind, if You're going to use aftermarket brakes with reduced clearance.
